Livestock Feed Pellet Plant

We Provide Livestock Feed Pellet Plant Turnkey Project That Will Produce Pellets With the World Standard Technologies!

  • Raw Materials
    Receiving System

  • Cleaning &
    Sieving System

  • Grinding
    System

  • Mixing
    System

  • Conditioning and
    Pelleting System

  • Cooling
    System

  • Screening
    System

  • Conveying
    System

  • Packaging
    System

The various raw materials required by the feed mill are put into storage or put directly into use through certain standardized procedures. Divided into bulk raw material receiving, packaged raw material receiving, liquid raw material receiving.

Clean out the impurities and iron-containing substances in the raw material, and let the clean materials enter the feed hammer mill for crushing. Its significance is to ensure the product quality and ensure the normal operation of the crusher.

The raw materials that need to be crushed enter the buffer bin after going through the cleaning section,and then enter the feed crushing machine. According to the requirements of the formula, the raw materials are crushed to a certain degree of fineness, and then transported to the next section without wind.

According to the requirements of the feed formula, different raw materials are mixed here with additives, oil/fat, medicines, etc. It is accurately weighed through the PLC control program, and the weighing, and mixing process is completed in the shortest time.

The crushed powder materials are pelletized, and feed pellets of different sizes can be produced by changing different ring dies. Pellet feed has comprehensive nutrition and strong stability, which can improve the digestibility of feed by animals, reduce animal picky eating, convenient storage and transportation, and economical.

The temperature of the pellets coming out of the pellet machine is 80 degrees, and the moisture is 15-16%. It is not suitable for packaging, so it needs to enter the counter-flow cooler to slowly cool the pellet feed to room temperature.

Through sieving, the qualified pellets are extracted, the unqualified small pellets or powder feed are sieved out and re-granulated, and the pellets whose geometric size is larger than the qualified pellet product are returned to the pellet crumbler machine for crumbling.

Our conveyors cover all feed processing sections throughout your feed plant.We can customize a conveying system by using any combination of bucket elevators,screw conveyors,scraper conveyors.

Finished feed need to be packed,ready to dispatch.Packaging system offers maximum flexibility. Matching requirements in product suitability and capacity. It is suitable for pellet feed and powder feed products,and can be manual or automatic bagging depends on requirement.

livestock

Starting livestock feed pellet plant has been a profitable business endeavor in many countries. Livestock feed pellet plant production line is mechanical equipment that specializes in making pig feed, horse feed, cattle feed, sheep feed, donkey feed, rabbit feed, and so on. How to make livestock feed? You need livestock feed pellet plant equipment. Herm machinery high performance livestock feed pellet plant line with an output range of 1 ton/hour to 100 ton/hour. Complete livestock feed pellet plant includes raw material storage, cleaning machine, crushing machine, mixing machine, livestock pellet feed pelletizer, cooling machine, screening machine, packaging systems, transportation and electronic control system.



Send Inquiry

How to Make Livestock Feed

How to make livestock feed? Livestock feed production line process
How to make livestock feed? Livestock feed production line process

(1) Raw Material Crushing Section:

The feed grinder can grind the raw material ingredients to the required size. The grind fitness is different of different grinders. We supply four types of feed grinders. The hammer mills are suitable for small-sized or medium-sized feed pelletizing plants. The wide chamber fine grinders and water drop hammer mills are usually used in large-sized and medium-sized feed pelletizing factories. The ultra fine feed grinder is designed for grinding raw materials of special aquatic feed.

(2) Feed Material Mixing Section:

Mixing is considered to be one of the essential operations in feed pellet processing. Lack of proper mixing may lead to reduced diet uniformity, affecting the feed pellet quality. We supply two kinds of high efficiency feed mixers: twin-shaft mixer for mixing powdered or particle materials and screw belt mixer for mixing powdered materials. Both of them can be equipped with atomizing spraying system to add needed liquids, which can improve the feed pellet quality.

(3) Feed Pelletizing Section:

Feed pellet mill is the main equipment of the whole production line. There are two common kind of feed pellet mills: ring die feed pellet mill and flat die feed pellet mill. If you want to produce feed pellets with large quantity, the ring die feed pellet mill is the ideal choice. If your demanded quantity is small, you can choose the flat die feed pellet mill. Also, we supply the aquatic feed pellet mill for pressing fish feed pellets and shrimp feed pellets etc. If you have more question about customized feed pellet production requirement, please feel free toleave message or send email for more support.

livestock feed pellet machine for sale livestock feed mill machine supplier
Send Inquiry

(4) Feed Pellet Cooling Section:

The feed pellets pressed out by the feed pellet mill are hot and moist. They can't be crushed, screened or packed immediately. Counterflow feed pellet cooler is designed to cool or dry the feed pellets. It can decrease the temperature and moisture of the feed pellets, preparing for the following Sectiones.

(5) Feed Pellet Crushing Section:

Different poultry, livestock or aquatic feed pellets are with different sizes. Some big ones should be crushed into small ones. Roll type feed pellet crumbler is just the equipment for feed pellet crushing. Double-roll feed pellet crumbler is suitable for crushing poultry feed, such as chicken feed, duck feed and goose feed etc. Three-roll feed pellet crumbler is suitable to crush aquatic feed including fish feed and shrimp feed etc.

(6) Feed Pellet Screening and Grading Section:

The crushed feed pellets are with different sizes, and there may be some powder. Therotary grading sieve can be used to screen and grade the feed pellets. After processing, you can get the qualified feed pellets without fine powder.

(7) Feed Pellet Packing Section:

The feed pellets should be packed for transporting, storing or selling. Automatic weighing and packing machine can weigh and pack the pellets automatically with high accuracy.

(8) Automatic PLC Control System:

With the automatic PLC control system, the production line is with high efficiency and convenient operation.

livestock feed mill machine livestock feed pellet making machine
Send Inquiry

Advantages of Feed Pellets

livestock and livestock feed

  1. Reduced selective feeding
  2. Decreased ingredient segregation
  3. Decreased feed wastage
  4. Destruction of pathogenic organisms
  5. Reduced storage spaces
  6. Allows partial gelatinisation of starch and modification of the protein in grains making them more susceptible to enzymatic action and better digestion.
  7. Reduced dustiness and increased palatability thus making for greater consumption
  8. Increased utilisation of fibrous fraction of feedstuffs
  9. Adaptable to bulk and mechanised feeding

livestock feed pellet machine price livestock feed pellet machine supplier
Send Inquiry

Raw Material

There are thousands of raw materials for livestock feed. The most common ones are soybean meal, cornmeal, bran, cotton cake, rapeseed cake, soybean cake, bone meal, baking soda, premix, salt, corn stalk, wheat stalk, soybean stalk, peanut Seedlings, sweet potato seedlings, pasture, weeds, straw, distiller's grains, tofu residue, etc. Under modern breeding conditions, the food structure of cattle is generally based on two types of forage and concentrated feed, which are appropriately matched with other roughage. Forages are generally based on fresh grass, hay, and tree stems and leaves. Common coarse materials include distiller's grains and tofu residue. So, forage or roughage is generally easy to find, and you can buy it directly from a raw material supplier.

Our Advantage

If your team is going to build a livestock feed pellet production line, the advantage of choosing us is that Herm will help you:

1.Determine the scale of livestock feed mill.

2.Determine the feed process and recommend livestock feed machine.

3.Control mode selection.

4.Livestock feed manufacturing plant structure selection.

5.Planning the general drawing of livestock feed mill plant site.

6.We devote ourselves to undertaking all livestock feed production line 1-100 t/h.

livestock feed pellet machine manufacturer livestock feed pellet machine
Send Inquiry

HERM Machinery Feed Pellet Equipment Project Distribution

No. Continent Country
1 Europe Russia, Ukraine, Netherlands, Belgium, Germany, Britain, Slovenia, Poland, Lithuania, Moldova, Bosnia and Herzegovina
2 America United States, Mexico, Peru, Colombia, Chile, Bolivia, Ecuador, Dominica, Bahamas, Puerto Rico, Trinidad and Tobago, Honduras, El Salvador, Panama
3 Asia Kazakhstan, Cambodia, Myanmar, Thailand, Malaysia, Canada, Indonesia, Russia, Uzbekistan, Philippines, Lebanon, Israel, Iraq, Saudi Arabia Arabia, Yemen, UAE, Qatar, Afghanistan, Sri Lanka, Bangladesh, Nepal, Oman, Cyprus, Syria, Georgia, Bahrain, Palestine, Pakistan, India
4 Africa Ethiopia, Tanzania, Algeria, Nigeria, Zimbabwe, Botswana, South Africa, Kenya, Tunisia, Libya, South Sudan, Somalia, Rwanda, Uganda, Mauritania, Senegal, Comoros, Malawi, Mozambique, Sudan, Gambia, Guinea , Cape Verde, Burkina Faso, Madagascar, Cameroon, Equatorial Guinea, Congo (DRC), Zambia, Angola, Sierra Leone, Ghana, Benin, Côte d’Ivoire
5 Oceania Australia, New Zealand, Papua New Guinea
