Rabbit Feed Production Machine Line

We Provide Rabbit Feed Production Machine Line Turnkey Project That Will Produce Pellets With the World Standard Technologies!

  • Raw Materials
    Receiving System

  • Cleaning &
    Sieving System

  • Grinding
    System

  • Mixing
    System

  • Conditioning and
    Pelleting System

  • Cooling
    System

  • Screening
    System

  • Conveying
    System

  • Packaging
    System

The various raw materials required by the feed mill are put into storage or put directly into use through certain standardized procedures. Divided into bulk raw material receiving, packaged raw material receiving, liquid raw material receiving.

Clean out the impurities and iron-containing substances in the raw material, and let the clean materials enter the feed hammer mill for crushing. Its significance is to ensure the product quality and ensure the normal operation of the crusher.

The raw materials that need to be crushed enter the buffer bin after going through the cleaning section,and then enter the feed crushing machine. According to the requirements of the formula, the raw materials are crushed to a certain degree of fineness, and then transported to the next section without wind.

According to the requirements of the feed formula, different raw materials are mixed here with additives, oil/fat, medicines, etc. It is accurately weighed through the PLC control program, and the weighing, and mixing process is completed in the shortest time.

The crushed powder materials are pelletized, and feed pellets of different sizes can be produced by changing different ring dies. Pellet feed has comprehensive nutrition and strong stability, which can improve the digestibility of feed by animals, reduce animal picky eating, convenient storage and transportation, and economical.

The temperature of the pellets coming out of the pellet machine is 80 degrees, and the moisture is 15-16%. It is not suitable for packaging, so it needs to enter the counter-flow cooler to slowly cool the pellet feed to room temperature.

Through sieving, the qualified pellets are extracted, the unqualified small pellets or powder feed are sieved out and re-granulated, and the pellets whose geometric size is larger than the qualified pellet product are returned to the pellet crumbler machine for crumbling.

Our conveyors cover all feed processing sections throughout your feed plant.We can customize a conveying system by using any combination of bucket elevators,screw conveyors,scraper conveyors.

Finished feed need to be packed,ready to dispatch.Packaging system offers maximum flexibility. Matching requirements in product suitability and capacity. It is suitable for pellet feed and powder feed products,and can be manual or automatic bagging depends on requirement.

Rabbits

Complete rabbit feed production machine line used Fine rice bran, Fish meal, Soybean meal, Corn, Wheat bran, Calcium hydrophosphate, Salt, Limestone, Additive, rough rice and other essential micro-ingredients to produce feed pellet. The pellets are very nutritional and can satisfy the growth needs of rabbit in different growth stages. By combining moisture, heat, and pressure on feed ingredients, a degree of gelatinization is produced, which allows rabbit to better utilize the nutrients in these ingredients. The feed pellets are widely used in small-sized farms and large-medium feed factories. Herm machinery high performance rabbit feed pellet plant production line includes grain hammer mills, conveyors, mixers, rabbit pellet feed making machine, coolers, crumbling machine, screening machine, automatic packing machine, etc. The 2-12mm cylindrical feed pellets can be produced according to your needs. Usually, meat rabbit:3-6mm pellet, rex rabbit:3-5mm pellet, young rabbit:2-3mm pellet, fattening rabbits:3-8mm pellet.

Send Inquiry

How to Make Rabbit Feed?

How to make rabbit feed? Rabbit feed production line process
How to make rabbit feed? Rabbit feed production line process

(1) Raw material receiving system

Shredded material: Pour the material to be crushed into the pit, transport it to the elevator through the scraper conveyor, lift it to the cylinder for preliminary cleaning and sieve, then enter the permanent magnet cylinder to oscillate, enter the distributor and be distributed to the silo to be crushed. To be crushed.

Feeding of auxiliary materials without crushing: transported by a scraper conveyor to a hoist, and then lifted to a cylindrical powder sieve, then enters the permanent magnet cylinder to oscillate, and then transported by a scraper conveyor to the distributor to be distributed to ingredients Warehouse, to be mixed ingredients.

(2) Crushing system

The material to be crushed is in the silo to be crushed, and enters the crusher through the feeder for crushing, and then the crushed material is transported to the elevator through the screw conveyor, and then is lifted to the distributor, and then enters the batching silo to be mixed.

(3) Batching mixing system

The batching in the batching bin is passed through an automatic batching scale to make the raw material mixing ratio to a fixed value, and a certain amount of grease is added at the same time. Then the raw materials enter the mixer for mixing, and then enter the smashing bin through the scraper conveyor for two After pulverization, it passes through the elevator to the finished product inspection sieve. After sieving, the particles that meet the particle size requirements enter the permanent magnet cylinder for oscillation, and then pass through the distributor to the granulation bin.

(4) Feed pelleting system

After the raw materials are crushed, they are granulated by a feed pellet machine in the granulation bin, and then enter the crusher for crushing after being cooled by a cooler, and then pass through the elevator to the grading screen. The particles that meet the requirements enter the finished product bin through the distributor. The particles that do not meet the requirements are batched through secondary mixing, enter the distributor through the batching scale, and then enter the pellet machine.

(5) Packaging system

The finished product is firstly packaged by a scale, then sealed with a sewing machine, and finally transported to the finished product warehouse by a belt conveyor.

Send Inquiry

Advantages of Feed Pellets:

Rabbit and rabbit feed

  1. Good liquidity. Easy to manage. Many powders, especially velvet feeds with a small specific gravity, often add molasses or high fat and urea feeds to the stock. Due to the good fluidity of the feed pellets, there is little sticking, and for those farms that use automated feeders to raise cows or poultry on a large scale, pellet feed is the most popular.
  2. High rate of return. In the pelletizing process, due to the combined action of water, temperature and pressure, some physical and chemical reactions occur in the feed, gelatinization of the starch, and enhanced activity of the enzyme, which enables the animals to digest the feed more efficiently and transform into an increase in body weight. Feeding poultry with pellet feed improves feed conversion compared to poultry powder feed.
  3. Transportation economy. After pelletization, the bulk density of the feed generally increased, which reduces the storage capacity and saves transportation costs.
  4. Reduce pollution. Avoid automatic grading of feed ingredients. In the powder storage and transportation process, due to the different volume and quality of various powders, it is easy to produce classification. After the pellets formed, there is no classification of the feed ingredients, and the pellets are not easy to dust, and the particulates have less air and moisture pollution than the powder during the feeding process.
  5. Avoid picky eaters. The compound poultry feed formula has a variety of raw materials and is comprehensive in nutrition, which prevents the animal from picking up the favorite food from the powder and refuses to ingest other ingredients. Feeding loss can reduce because the pellet feed maintains uniformity during storage and feeding.
  6. Sterilization. Salmonella in animal feed. Salmonella retained in animal tissues when it is ingested by animals. Animal who eat this bacteria will get Salmonella gastrointestinal problems. The method of re-granulation by steam high-temperature quenching and tempering can kill the presence of Salmonella in animal feed.
Send Inquiry

Raw Material

Our Advantage

If your team is going to build a rabbit feed pellet production line, the advantage of choosing us is that Herm will help you:

  1. Determine the scale of rabbit feed mill.
  2. Determine the feed process and recommend rabbit feed machine.
  3. Control mode selection.
  4. Rabbit feed manufacturing plant structure selection.
  5. Planning the general drawing of rabbit feed mill plant site.
  6. We devote ourselves to undertaking all rabbit feed production line 1-100 T/H.

Investment Guide

Production Scale Project Site Requirements Production cycle Installation cycle Investment Cost(USD) Profit cycle
1-2 T/H Feed Pellet Production Line 300-500m² 20 Days 7-15 Days 10000-50000 1-3 Year
3-4 T/H Feed Pellet Production Line 300-700m² 20 Days 15-20Days 5,0000-12,0000
5-7 T/H Feed Pellet Production Line 400-800m² 20-30 Days 20-40Days 7,0000-25,0000
8-10 T/H Feed Pellet Production Line 800-2000m² 30-40 Days 45-60 Days 150,000-300,000
12-20 T/H Feed Pellet Production Line 1500-3000m² 40-50 Days 60-90 Days 250,000-580,000
25-40 T/H Feed Pellet Production Line 2000-4000m² 50-60 Days 90-120Days 45,0000-850,000
50-60 T/H Feed Pellet Production Line 3000-5000m² 60-70 Days 100-140 Days 900,000-1,400,000
60-72 T/H Feed Pellet Production Line 5000-8000m² 70-90 Days 130-160 Days 1,450,000-1,800,000
80-100 T/H Feed Pellet Production Line 8000-20000m² 90-120 Days 160 -190Days 2,000,000-2,800,000
About the cost(different types & same capacity):
Poultry Feed Pellet Mill Plant, Ruminant Feed Pellet Mill Line, Livestock Feed Pellet Production Plant, Aquatic Pellet Extruder Plant, Pet Feed Pellet Mill Plant, Premix Feed Processing Plant, Powder Feed Production Line
About the profit :
1. The price of raw materials and feed is different in each country, and the investment cost will fluctuate.
2. The customer's operating costs include site costs, worker wages, and water and electricity costs. Skilled operators can minimize the operating costs of the equipment.
3. The correct management of feed mills, process management and high-quality production line equipment are the basis for the development of feed processing plants and high returns.
