We Provide 60-72T/H Feed Pellet Production Line Turnkey Project That Will Produce Pellets With the World Standard Technologies!
KINDLY REMINDER: If you are interested in our products, Please get in contact with us
Herm machinery CE approved computer control 60-72 t/h feed pellet production line is suitable for processing various animal feeds, such as cattle feed, sheep feed, camel feed, alpaca feed, chicken feed, fish feed, Shrimp feed, crab feed, pet dog food, pet cat food, bird feed, duck feed, goose feed, horse feed, pig feed, rabbit feed, etc. It is also suitable for processing various pre-mixed feeds and additive premix. 60-72 tons per hour feed pellet processing line is specially designed for the large--scale chain operation feed mills, and the animal feed suppliers who first begin to enter the animal feed production industry.
(1) Raw Material Crushing Section:
The feed grinder can grind the raw material ingredients to the required size. The grind fitness is different of different grinders. We supply four types of feed grinders. The hammer mills are suitable for small-sized or medium-sized feed pelletizing plants. The wide chamber fine grinders and water drop hammer mills are usually used in large-sized and medium-sized feed pelletizing factories. The ultra-fine feed grinder is designed for grinding raw materials of special aquatic feed.
(2) Feed Material Mixing Section:
Mixing is considered to be one of the essential operations in feed pellet processing. Lack of proper mixing may lead to reduced diet uniformity, affecting the feed pellet quality. We supply two kinds of high-efficiency feed mixers: a twin-shaft mixer for mixing powdered or particle materials and a screw belt mixer for mixing powdered materials. Both of them can be equipped with atomizing spraying systems to add needed liquids, which can improve the feed pellet quality.
(3) Feed Pelletizing Section:
The feed pellet mill is the main equipment of the whole production line. There are two common kinds of feed pellet mills: ring die feed pellet mill and flat die feed pellet mill. If you want to produce feed pellets in large quantities, the ring dies feed pellet mill is the ideal choice. If your demanded quantity is small, you can choose the flat die feed pellet mill. Also, we supply the aquatic feed pellet mill for pressing fish feed pellets and shrimp feed pellets, etc. If you have more questions about customized feed pellet production requirements, please feel free to leave a message or send an email for more support.
(4) Feed Pellet Cooling Section:
The feed pellets pressed out by the feed pellet mill are hot and moist. They can't be crushed, screened, or packed immediately. Counterflow feed pellet cooler is designed to cool or dry the feed pellets. It can decrease the temperature and moisture of the feed pellets, preparing for the following Sections.
(5) Feed Pellet Crushing Section:
Different poultry, livestock, or aquatic feed pellets are of different sizes. Some big ones should be crushed into small ones. Roll type feed pellet crumbler is just the equipment for feed pellet crushing. Double-roll feed pellet crumbler is suitable for crushing poultry feed, such as chicken feed, duck feed, and goose feed, etc. Three-roll feed pellet crumbler is suitable to crush aquatic feed including fish feed and shrimp feed etc.
(6) Feed Pellet Screening and Grading Section:
The crushed feed pellets are of different sizes, and there may be some powder. The rotary grading sieve can be used to screen and grade the feed pellets. After processing, you can get qualified feed pellets without fine powder.
(7) Feed Pellet Packing Section:
The feed pellets should be packed for transporting, storing, or selling. An automatic weighing and packing machine can weigh and pack the pellets automatically with high accuracy.
(8) Automatic PLC Control System:
With the automatic PLC control system, the production line is with high efficiency and convenient operation.
| NO. | Name | Model | Power（kw） | Quantity |
| 1 | Screw conveyor | TLSS25 | 3 | 4 |
| 2 | Feed hammer mill | SFSP66*100 | 132 | 2 |
| 3 | Feed hammer mill | SFSP138*50E | 132 | 2 |
| 4 | Powder cleaning sieve | SCQZ90*80*110 | 5.5 | 2 |
| 5 | Drum type precleaner | SCY80 | 0.75 | 2 |
| 6 | Single-shaft mixer | SLHJ6.0A | 55 | 2 |
| 7 | Feed pellet machine | SZLH508 | 160 | 4 |
| 8 | Cooling Machine | SKLN24x24 | 2.2 | 4 |
| 9 | Crumbling machine | SSLG20*170 | 15 | 4 |
| 10 | Rotary screener | SFJZ150*2C | 5.5 | 4 |
| 11 | Auto Packing machine | DCS-50 | 3 | 4 |
The raw material of feed pellets includes plant protein and animal protein. Plant protein comes from soybeans, soybean meal, alfalfa, wheat bran, grass, rice, beans, sweet sorghum, oil cake, etc. Animal protein is from fish meal, shrimp meal, crab meal, bone meal, amino acid, fusel meal, sleeve-fish meal, and so on. You can add another ingredient according to the requirements and eating habits of animals.
raw materials used in the 60-72 t/h feed pellet production line
Establish a complete feed pellet production line, can improve work efficiency, reduce feed costs, for users to increase profits. It can not only suppress cattle and sheep feed but also can process pig, chicken, duck, and other feed pellets. When making your feed particles, different materials can be added according to the different needs of animals to ensure the safety of feed and the comprehensive nutrition of animals. Feeding granulated feed can increase animal intake and avoid animal pickiness, which is conducive to digestion and absorption. It can shorten the growth period of animals, easy to transport, and can be kept for half a year.
Herm Machinery CE approved computer control 60-72 t/h feed pellet mill plant production line is widely applied to large-scale feed pellet production line of animal feed pellets. It can produce 60-72 ton per hour pellet feed per hour. The manufactured pellet feed is suitable for raising chicken, duck, goose, bird, cow, cattle, sheep, camels, alpacas, horse, pig, rabbit, fish, shrimp, crab, cat, dog, and other animal feed processing and production.
