We Provide 8-12T/H Feed Pellet Production Line Turnkey Project That Will Produce Pellets With the World Standard Technologies!
KINDLY REMINDER: If you are interested in our products, Please get in contact with us
Herm machinery CE ISO approved good quality 8-12 t/h feed pellet production line is suitable for processing various animal feeds, such as chicken feed, bird feed, duck feed, goose feed, cattle feed, sheep feed, camel feed, alpaca feed, horse feed, pig feed, rabbit feed, fish feed, Shrimp feed, crab feed, pet dog food, pet cat food, etc. It is also suitable for processing various pre-mixed feeds and additive premix. The main equipment of a complete 8-12T/H feed pellet production line includes 110kw hammer mill machine, 8-12 t/h feed pellet making machine, 15kw single shaft screw mixer, counter-flow feed pellet cooler, pellet crumbler machine, box cylinder pulse dust remover, vibrating screen classifier, bucket elevator,automatic bagging system,etc.
(1) Raw material receiving system
Shredded material: Pour the material to be crushed into the pit, transport it to the elevator through the scraper conveyor, lift it to the cylinder for preliminary cleaning and sieve, then enter the permanent magnet cylinder to oscillate, enter the distributor and be distributed to the silo to be crushed. To be crushed.
Feeding of auxiliary materials without crushing: transported by a scraper conveyor to a hoist, and then lifted to a cylindrical powder sieve, then enters the permanent magnet cylinder to oscillate, and then transported by a scraper conveyor to the distributor to be distributed to ingredients Warehouse, to be mixed ingredients.
(2) Crushing system
The material to be crushed is in the silo to be crushed, and enters the crusher through the feeder for crushing, and then the crushed material is transported to the elevator through the screw conveyor, and then is lifted to the distributor, and then enters the batching silo to be mixed.
(3) Batching mixing system
The batching in the batching bin is passed through an automatic batching scale to make the raw material mixing ratio to a fixed value, and a certain amount of grease is added at the same time. Then the raw materials enter the mixer for mixing, and then enter the smashing bin through the scraper conveyor for two After pulverization, it passes through the elevator to the finished product inspection sieve. After sieving, the particles that meet the particle size requirements enter the permanent magnet cylinder for oscillation, and then pass through the distributor to the granulation bin.
(4) Feed pelleting system
After the raw materials are crushed, they are granulated by a feed pellet machine in the granulation bin, and then enter the crusher for crushing after being cooled by a cooler, and then pass through the elevator to the grading screen. The particles that meet the requirements enter the finished product bin through the distributor. The particles that do not meet the requirements are batched through secondary mixing, enter the distributor through the batching scale, and then enter the pellet machine.
(5) Packaging system
The finished product is firstly packaged by a scale, then sealed with a sewing machine, and finally transported to the finished product warehouse by a belt conveyor.
Herm Machinery CE ISO approved good quality feed mill plant production line is widely applied to medium scale and large feed pellet production line of animal feed pellets. It can produce 8-12 t/h pellet feed per hour. The manufactured pellet feed is suitable for raising cow, cattle, sheep, camels, alpacas, horse, pig, rabbit, chicken, duck, goose, bird, fish, shrimp, crab, cat, dog and other animal feed processing and production.
Raw material of feed pellets include plant protein and animal protein. Plant protein comes from soybeans, soybean meal, alfalfa, wheat bran, grass, rice, beans, sweet sorghum, oil cake, etc. Animal protein is from fish meal, shrimp meal, crab meal, bone meal, amino acid, fusel meal, sleeve-fish meal and so on. You can add other ingredient according to requirements and eating habits of animals.
raw materials used in the 8-12 t/h feed pellet production line
Send Inquiry
| NO. | Name | Model | Power（kw） | Quantity |
| 1 | Screw conveyor | TLSS25 | 2.2 | 1 |
| 2 | Feed hammer mill | SFSP66*60 | 75 | 1 |
| 3 | Powder precleaner | SCQZ60*50*100 | 5.5 | |
| 4 | Double Ribbon Mixer | SLHY2.5L | 18.5 | 1 |
| 5 | Feed pellet machine | SZLH420 | 110 | 1 |
| 6 | Cooling Machine | SKLN20×20 | 1.5 | 1 |
| 7 | Crumbling machine | SSLG15X150 | 7.5 | 1 |
| 8 | Rotary screener | SFJH125*2C | 4 | 1 |
| 9 | Auto Packing machine | DSC-50 | 3 | 1 |
